INSTALLATION
/ 23
Height = 267mm
3318092
Height = 296 mm
Fig. 6
Fig. 7
Fitting the Coaxial Flue
(Ø 60 / 100 Vertical)
Note: See table for maximum and minimum ue runs.
Contents:
1x Conical Adaptor (60/100mm)
1x Vertical Flue Kit (80/125mm)
The vertical ue kit is supplied with a specially designed
weather proof terminal tted, it can be used either with a at
roof or a pitched roof.
The Vertical ue kits useable lengths with the pitched roof
ashings are indicated in Fig. 7.
180 mm
Vert Adaptor
(supplied with ue kit)
Vertical Starter
Part No: 3318079
* This length will vary
according to the type
of ashing installed
Total length
of Vertical Kit
1355 mm
Useable length
of Vertical ue
690 mm*
Fig. 7
Fig. 8
Before proceeding to t the ue, ensure that the maximum ue length has not been exceeded (See the tables) and that all elbows
and bends have been taken into consideration, for each additional 90° elbow 1 metre must be subtracted from the total ue length,
and for each 45° 0.5 metres must be subtracted from the total ue length (the height of the vertical adaptor and a 45° bend can be
seen in Fig.6 and a 90° bend in Fig. 7).
NOTE: DO NOT CUT THE VERTICAL FLUE KIT.
Before proceeding to t the ue, ensure that the maximum
ue length has not been exceeded (See the tables) and that
all elbows and bends have been taken into consideration, for
each additional 90° elbow 1 metre must be subtracted from
the total ue length, and for each 45° 0.5 metres must be
subtracted from the total ue length (the height of the vertical
adaptor and a 45° bend can be seen in Fig. 8).
Mark the position of the ue hole in the ceiling and/or roof (see
Fig. 7 for distance from wall to the centre of the ue).
Cut a 130mm diameter hole through the ceiling and/or roof and
t the ashing plate to the roof.
