Ariston ALTEAS ONE+ NET User Manual

MAINTENANCE GUIDE
/ 52
1. GENERAL ACCESS
1.1 General Access
Tools
TIME 3 min
Remove the two screws
1
CAUTION!!
REMOVE ONLY THE SCREWS SHOWN
IN THE PICTURE
1.0 Disconnect the boiler
Before beginning maintenance work:
a. Disconnect the appliance from the electricity supply.
Press the ON/OFF button and wait 1 minute (the 3-way
valve turn on Stand-by position)
ATTENTION!! With the 3-way valve on heating position
is not possible to remove the motor.
Turn the to the “OFF” position.
b. Close the gas valve and the central heating and domestic
hot water system valves.
1
Remove the front panel
2
Lower the electrical front panel
3

Ariston ALTEAS ONE+ NET Specifications

General

Type	Condensing Boiler
Energy Rating	A
Modulation	1:10
NOx Emissions	Class 6
Efficiency	94%
Output	24 kW
Control	Touchscreen
Fuel Type	Natural Gas
Connectivity	Wi-Fi
Heating Capacity	24 kW
DHW Flow Rate	Up to 14.3 l/min
