Ariston ALTEAS ONE+ NET

MAINTENANCE GUIDE
/ 53
2. ELECTRICAL UNIT
2.1 Control box access
Tools
TIME 4 min
Remove the front panel as above and pivot the electricl box
1
Unhook the two clip and remove the cover
2
Unscrew the two screws and remove the cover of the
instrument panel to have access to the main P.C.B.
3
4
2.2 Fuse
Tools
TIME 5 min
Open the control box as above
1
Remove the fuse
2
3
