2.3 Main P.C.B.
Tools
TIME 5 min
After opening the control box, disconnect the elctrical plug
connections
1
Unhook and remove the P.C.B.
2
2.4 Display P.C.B.
Tools
TIME 5 min
Unscrews the two screws and pull the assembly towards you
1
Disconnect the elctrical plug connections
2
Front
