MAINTENANCE GUIDE
/ 66
4.1 Electrode (detection and ignition)
Tools
TIME 5 min
Unplug the electrode on the control box
Remove the screws and pull the electrodes towards you.
1
2
4.2 Burner
Tools
TIME 15 min
Remove the silencer
1
Isolate the gas supply. Disconnect the gas pipe.
2
Disconnect the cable of the electrode.
Remove the four nuts and remove the burner unit
3
