Ariston NIMBUS M NET User Manual

User menu
11 / EN
3. User menu
– On the home page press the “Menu” button to access
the user menu.
– The display will show the user menu consisting of two
pages.
– Turn the selector
to highlight the desired menu.
– Press the selector
to access the selected menu.
– To access the second page, turn the selector and scroll
the cursor past the last icon of the first page.
Page 1
1
Zones
management
Holiday function
Time program
System operation
modes
Consumptions
history
DHW settings
Fig. 16
SYMBOLS Description
Zones Allows you to check the main information on the operating status of the zones and to set the
operating mode of the single zone.
Time
scheduling
Allows you to choose the type of operation:
SCHEDULED
the system will operate according to the set schedule.
MANUAL
the system will operate in continuous mode
Energy
consumption
Shows the estimated energy consumption (gas and electricity) and their performance over time for
the heating, cooling and domestic hot water modes.
Holiday
function
The holiday function disables the heating during the holiday period and sets the room heating and
domestic hot water system to anti-frost protection until the set date.
Operating
mode
Can be used to select the operating mode:
SUMMER
domestic hot water production, space heating off.
WINTER
domestic hot water production and space heating on.
HEATING ONLY
indirect cylinder heating off (where present).
COOLING AND DOMESTIC HOT WATER
(if present).
COOLING ONLY
indirect cylinder heating off (where present).
OFF
system off, anti-frost function enabled.
Domestic hot
water settings
Can be used to select the desired temperature, the operating mode for domestic hot water
production and the thermal sanitisation function of the DHW storage tank (if present).

Ariston NIMBUS M NET Specifications

General

Type	Air-to-Water Heat Pump
Refrigerant	R32
Power Supply	Electric
Power Supply Voltage	230 V
Connectivity	Wi-Fi
Heating Capacity	6 kW
