3.2.2 Heating/Cooling time schedule - Multi-level
In the multi-level time scheduling, the sequence of operations
is similar to the two-level process (refer to the paragraph “
Heating/Cooling time scheduling - 2 levels”), except for the
following steps:
– The page for setting the comfort and reduced
temperatures will not be displayed.
– In the page for defining the time slot you can select a
dedicated set-point value. The range is 10° - 30°C for
each of the time slots created.
– Up to 12 daily time slots can be selected.
Defining the time slot
Zone 1
Scenario Free Sunday
Start 04:30
18°
,0
End 06:30
16,0° 18,0° 19,0°22,0° 15,0° 15,0° 22,0° 16,0°
0 2 4 6 8 10 12 16 20 14 18 22 24
Fig. 32
3.2.3 DHW time program
Defining the comfort and reduced set-point temperatures
Domestic hot water
DHW comfort setpoint temp.
55°C
DHW reduced setpoint temp. 35°C
Set time program >
Fig. 33
– Turn the selector
to navigate to “DHW comfort
setpoint temp.” or “DHW reduced setpoint temp.”.
– Press the selector
to enter the edit mode. Turn the
selector to define the temperature set-point.
– Press the selector
to confirm.
– The “Set time program” allows the user to define the day
of the week to be scheduled.
Selecting the type of time schedule: free or pre-set
DHW
Scenario
Free
55°
55°
0 2 4 6 8 10 12 16 20 14 18 22 24
Sunday
Monday
Tuesday
55°
Save
Fig. 34
– Press the selector
to enter the edit mode.
– Select “Free” to proceed with the creation of a
customised weekly schedule, otherwise select one of
the pre-set profiles:
– "Family"
– "No lunch"
– "Midday"
– "Always active"
– "Green"
– Press the selector
to confirm “Scenario”.
– Turn the selector
to move to the selection of the
day of the week to be scheduled.
