Arjo Concerto electric - Horizontal Position; Horizontal Lock (Concerto); Adjustable Back Support (Accessory for Concerto); Wedge Pillow (Accessory)

11
The shower trolley always adjust
automatically to a horizontal posi-
tion when it is lowered onto a bed.
The trolley is also equipped with a
special fitting which locks it in a hori-
zontal position for transport or when
the mattress is to be filled with water.
Move the lever (A) to the right and the
trolley is locked in horizontal position.
Pull the back support to the desired
position when you want to raise it.
Make sure that the catch is in a locked
position.
To lower, press the catches (A) while
lowering the back support carefully.
The wedge pillow can be placed at the
top end of the mattress for higher
comfort.
Horizontal position
Horizontal lock (Concerto)
A
A
djustable back support (accessory for Concerto)
A
Wedge pillow (accessory)
