9
The side support is fold down by pres-
sing the two catches simultaneously.
When raising the side supports, make
sure the two catches snap into place.
The wheels are braked by pressing the
wheel lock tab (A) with your foot.
The wheels are released by pressing
down the centre tab (B).
To facilitate transportation in corri-
dors etc., the
Concerto
is fitted with
straight
steering device.
The straight steering is activated by
pressing the tab with your foot.
Release by lifting the tab with your
foot.
The support at the top end of the sho-
wer trolley can be adjusted to alter the
length of the stretcher. Unscrew the
two screws and move the support to
the desired position. Then tighten the
screws securely.
Side supports
Brakes
A
B
Straight steering (Concerto)
Length adjustment of stretcher
