Arjo Concerto electric - Introduction; Part Designations

6
The
Concerto
is available in two
different versions, oil hydraulic and
electrical battery operated.
The Basic is oil hydraulic operated.
1 Shower mattress
2 Hand control (Concerto electric)
3 Stretcher
4 Battery (Concerto electric)
5 Straight steering (Concerto)
6 Wheel brake
7 Drainage
8 Catches for side support
9 Side support
10 Filling plug for hydraulic oil
(Concerto electric)
11 Horizontal lock (Concerto)
12 Pedal for raising/lowering
(Concerto hydraulic, Basic)
13 Filling plug for hydraulic oil
(Concerto hydraulic, Basic)
Introduction
Concerto hydraulicConcerto electric Basic
Part designations
2
3
5
4
1
7
6
8
12
9
11
10
13
