Guidance and manufacturer’s declaration: electromagnetic immunity
Immunity test IEC60601 test level Compliance level Electromagnetic environment
- guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±8kV contact
±15kV air
±8kV contact
±15kV air
Floors should be wood,
concrete or ceramic tile.
,IÀRRUVDUHFRYHUHGZLWK
synthetic material the relative
humidity level should be at
least 30%
Conducted RF
IEC 61000-4-6
3 V outside ISM bands
between
0.15-80 MHz
6 V inside ISM and
amateur radio bands
between 0.15 - 80 MHz
3 V outside ISM bands
between
0.15-80 MHz
6 V inside ISM and
amateur radio bands
between 0.15 - 80 MHz
N/A
Radiated RF
IEC 61000-4-3
10V/m
80MHz to 2.7GHz
10V/m
80MHz to 2.7GHz
Electrical fast
transient/burst
IEC 61000-4-4
±1 kV, I/O Ports
100 kHz repetition
frequency
±1 kV, I/O Ports
100 kHz repetition
frequency
Mains power supply
should be that of a typical
commercial or hospital
environment.
Power frequency
(50/60 Hz)
0DJQHWLF¿HOG
IEC 61000-4-8
30 A/m
50/60 Hz
30 A/m
50/60 Hz
If functional disturbance
occurs on Sara Flex it may
be necessary to install
magnetic shielding. The
power frequency magnetic
¿HOGVKRXOGEHPHDVXUHG
prior to installation to assure
WKDWLWLVVXI¿FLHQWO\ORZ
3UR[LPLW\¿HOGV
from RF wireless
communications
equipment
IEC 61000-4-3
380 - 390 MHz
27 V/m; PM 50%; 18 Hz
430 - 470 MHz
28 V/m; (FM ±5 kHz, 1
kHz sine) PM; 18 Hz
704 - 708 MHz
9 V/m; PM 50%; 217 Hz
800 - 960 MHz
28 V/m; PM 50%; 18 Hz
1700 - 1990 MHz
28 V/m; PM 50%; 217 Hz
2400 - 2570 MHz
28 V/m; PM 50%; 217 Hz
5100 - 5800 MHz
9 V/m; PM 50%; 217 Hz
380 - 390 MHz
27 V/m; PM 50%; 18 Hz
430 - 470 MHz
28 V/m; (FM ±5 kHz, 1
kHz sine) PM; 18 Hz
704 - 708 MHz
9 V/m; PM 50%; 217 Hz
800 - 960 MHz
28 V/m; PM 50%; 18 Hz
1700 - 1990 MHz
28 V/m; PM 50%; 217 Hz
2400 - 2570 MHz
28 V/m; PM 50%; 217 Hz
5100 - 5800 MHz
9 V/m; PM 50%; 217 Hz
N/A
