Arjo Sara Flex - Product Description; Functions; Controls and Features

9
Product Description / Functions
Controls and Features
Hand control (See Fig. 2)
Use the hand control to:
• Raise/lower the lifting arm on Sara Flex.
• Open/close the chassis legs on Sara Flex.
• The dash buttons are used for menu operations.
Button Functions:
Up
Down
Close lift legs
Open lift legs
Right Dash
Left Dash
If a pressed button is released, it will stop its function
immediately.
Control Panel (See Fig. 3)
The mast-mounted control panel operates in parallel
with the hand control. Sara Flex can also be controlled
from the mast.
Button Functions:
Up
Down
Close lift legs
Open lift legs
Fig. 2
Fig. 3
