Armstrong 3750 - Building Automation System (Single System) - BACnet MS;TP

installation &
operating instructions
3750 Pulpress
Pressurisation unit
23
Building Automation System (Single System) – BACnet MS/TP
bacnet
address
signal
type
data
type
read/
write
description range units
0 Digital Bool r/w Remote Start on/off Toggle
1 Analog Integer r/w Pump 1 Mode 0- O, 1-Hand, 2-Auto
2 Analog Integer r/w Pump 2 Mode 0- O, 1-Hand, 2-Auto
3 Analog Integer r/w Number of Pumps 1 to 2 Numeric
4 Analog Integer r/w Excessive Number of Start num 1 to 99 Numeric
5 Analog Integer r/w Excessive Start min 1 to 720 Minute
6 Analog Real r/w Max Pump Run Time 1 to 990 Minute
7 Analog Real r/w Pump Pulse Cyc Start interval 1 to 8640 Hours
8 Analog Integer r/w Pump Pulse Cycle Time 1 to 99 Seconds
9 Analog Real r/w Pump Cut Out Fill Pressure 0 to Pump COP High Limit Bar/PSI/Kpa/m/ft
10 Analog Real r/w Pump Cut In Fill Pressure 0 to Pump COP High Limit Bar/PSI/Kpa/m/ft
11 Analog Real r/w High Pressure Alarm Setting 0 to Pressure Transducer High Range Bar/PSI/Kpa/m/ft
12 Analog Real r/w Low Pressure Alarm Setting 0 to Pressure Transducer High Range Bar/PSI/Kpa/m/ft
13 Analog Real r/w Pressure Dip Delay 0 to 100 Seconds
14 Analog Real r/w Pressure Transducer Zero Range 0 to 9999 Bar/PSI/Kpa/m/ft
15 Analog Real r/w Pressure Transducer High Range 0 to 9999 Bar/PSI/Kpa/m/ft
16 Analog Integer r/w bas Protocol 0-Modbus,1-BACnet, 2-N/A
17 Analog Integer r/w bas Address 1 to 127
18 Analog Integer r/w bas Baudrate 0-9600, 1-19200, 2-38400
19 Analog Integer r/w BACnet Instance 0-999 Numeric
41 Analog Integer r/w Pressure Unit Selection 0-Bar, 1-PSI, 2-KPa, 3-meter, 4-foot Units
42 Analog Integer r/w Pressure Unit Selection for Sensor 0-Bar, 1-PSI, 2-KPa, 3-meter, 4-foot Units
20 Analog Real r Pressure Transducer Bar/PSI/Kpa/m/ft
21 Analog Integer r Pump 1 Hour Run Hours
22 Analog Integer r Pump 2 Hour Run Hours
23 Analog Integer r Pump 1 HOA 0-O, 1-Hand, 2-Auto
24 Analog Integer r Pump 2 HOA 0-O, 1-Hand, 2-Auto
25 Digital Bool r Pump 1 Command on/off
26 Digital Bool r Pump 2 Command on/off
27 Digital Bool r Heater on Panel on/off
28 Digital Bool r General Alarm on/off
29 Digital Bool r Transducer Failure Alarm on/off
30 Digital Bool r Both Pumps Tripped Alarm on/off
31 Digital Bool r Max Pump Run Time Alarm on/off
32 Digital Bool r Excessive Pump Start Alarm on/off
33 Digital Bool r Low System Pressure Alarm on/off
34 Digital Bool r High System Pressure Alarm on/off
35 Digital Bool r Low Water Level Alarm on/off
36 Digital Bool r High Water Level Alarm on/off
37 Digital Bool r Pump 1 Tripped Alarm on/off
38 Digital Bool r Pump 2 Tripped Alarm on/off
39 Digital Bool r Service Reminder Alarm on/off
40 Digital Bool r/w Alarm Reset on/off Toggle
43 Digital Bool r Boiler Interlock Alarm on/off
44 Digital Bool r Device Oine Alarm on/off
