Armstrong 3750 - Building Automation System (Twin System) - BACnet MS;TP

installation &
operating instructions
3750 Pulpress
Pressurisation unit
26
bacnet
address
signal
type
data
type
read/
write
description range units
15 Analog Real r/w System 1 Low Pressure Alarm Setting
0 to System 1 Pressure Transducer
High Range
Bar/PSI/Kpa/m/ft
16 Analog Real r/w System 2 Pump Cut Out Fill Pressure 0 to Pump cop High Limit Bar/PSI/Kpa/m/ft
17 Analog Real r/w
System 2 Pump Cut In Fill Pressure-
Di
0 to Pump cop High Limit Bar/PSI/Kpa/m/ft
18 Analog Real r/w System 2 High Pressure Alarm Setting
0 to System 2 Pressure Transducer
High Range
Bar/PSI/Kpa/m/ft
19 Analog Real r/w System 2 Low Pressure Alarm Setting
0 to System 2 Pressure Transducer
High Range
Bar/PSI/Kpa/m/ft
20 Analog Real r/w Pressure Dip Delay 0 to 100 Seconds
21 Analog Real r/w
System 1 Pressure Transducer Zero
Range
0 to 9999 Bar/PSI/Kpa/m/ft
22 Analog Real r/w
System 1 Pressure Transducer High
Range
0 to 9999 Bar/PSI/Kpa/m/ft
23 Analog Real r/w
System 2 Pressure Transducer Zero
Range
0 to 9999 Bar/PSI/Kpa/m/ft
24 Analog Real r/w
System 2 Pressure Transducer High
Range
0 to 9999 Bar/PSI/Kpa/m/ft
25 Analog Integer r/w bas Protocol 1-n/a, 2-n/a, 3-Modbus, 4-BacNet Numeric
26 Analog Integer r/w bas Address 1 to 127 Numeric
27 Analog Integer r/w bas Baudrate 0-9600, 1-19200, 2-38400 Numeric
28 Analog Integer r/w Pressure Unit Selection 0-Bar, 1-PSI, 2-KPa, 3-meter, 4-foot Units
29 Analog Integer r/w Pressure Unit Selection for Sensor 0-Bar, 1-PSI, 2-KPa, 3-meter, 4-foot Units
30 Analog Integer r System 1 Pressure Transducer Bar/PSI/Kpa/m/ft
31 Analog Integer r System 2 Pressure Transducer Bar/PSI/Kpa/m/ft
32 Analog Integer r Pump 1 Hour Run Hours
33 Analog Integer r Pump 2 Hour Run Hours
34 Analog Integer r Pump 1 HOA 0-O, 1-Hand, 2-Auto Numeric
35 Analog Integer r Pump 2 HOA 0-O, 1-Hand, 2-Auto Numeric
36 Digital Bool r Pump 1 Command on/off
37 Digital Bool r Pump 1 Command on/off
38 Digital Bool r Heater ON Panel on/off
39 Digital Bool r System 1 General Alarm on/off
40 Digital Bool r System 1 Transducer Failure Alarm on/off
41 Digital Bool r System 2 Transducer Failure Alarm on/off
42 Digital Bool r Both Pumps Tripped Alarm on/off
43 Digital Bool r Max Pump Run Time Alarm on/off
44 Digital Bool r System 1 Excessive Pump Start Alarm on/off
45 Digital Bool r System 2 Excessive Pump Start Alarm on/off
46 Digital Bool r System 1 Low System Pressure Alarm on/off
47 Digital Bool r System 1 High System Pressure Alarm on/off
48 Digital Bool r System 2 Low System Pressure Alarm on/off
49 Digital Bool r System 2 High System Pressure Alarm on/off
50 Digital Bool r Low Water Level Alarm on/off
51 Digital Bool r High Water Level Alarm on/off
52 Digital Bool r Pump 1
Tripped Alarm on/off
53 Digital Bool r Pump 2 Tripped Alarm on/off
54 Digital Bool r Service Reminder Alarm on/off
55 Digital Bool r System 1 Boiler Interlock Alarm on/off
56 Digital Bool r System 2 Boiler Interlock Alarm on/off
57 Digital Bool r Device 1 Oine Alarm on/off
58 Digital Bool r Device 2 Oine Alarm on/off
