Armstrong 4380 - Networking Protocols; 3.1 Modbus IP & RTU

installation &
operating instructions
Design Envelope 4300 & 4380
Vertical In-line Pumping Unit
16
3.0 networking controls
Setup of bas protocol, Node address, baud rate, and for ip setup
3.1 modbus ip & rtu
modbus address value range description
10005 1 = Hand mode Pump in Hand mode
10006 1= o Pump is o
10007 1 = auto Pump is in automatic mode
10035 0 = stopped, 1 = running Run feedback
10069 0 = ok, 1 = alarm
Pump alarm
10079
0 = ok, 1 = alarm
Run feedback alarm
10089 0 = ok, 1 = alarm Pump drive fault
152 Set pump to hand mode
153 Set pump to o
154 Set pump to auto mode
30041 0-1000 (0%-100%) Pump speed
30054 0-10000 (0-1000.0) amps Pump drive current
30055 0-10000 (0-1000.0) VAC Pump drive AC voltage
30056 0-10000 (0-1000.0) kW Pump drive power
30057 0-1000 (0.0-100.0) % Pump drive speed feedback
30094 0-32767 (0.0-3276.7) Pump head
40139 0-1000 (0.0-100.0) % Pump hand speed
40151 0-9999 (0.0-999.9) Design head
40152 0-9999 (0.0-999.9) Zero flow head
35005 0-32767 Pump flow
35016 0-999 hours Pump operating run hours
35017 0-32000 hours * 1000 Pump operating run Khours
45052 0-32767 (0-327670) Flow design
