Armstrong 4380 - 3.2 BACnet IP & MS;TP

installation &
operating instructions
Design Envelope 4300 & 4380
Vertical In-line Pumping Unit
17
3.2 BACnet ip & ms/tp
name value range description
DO004 1 = Hand mode Pump in Hand mode
DO005 1= o Pump is o
DO006 1 = auto Pump is in automatic mode
DO034 0 = stopped, 1 = running Run feedback
DO068 0 = ok, 1 = alarm Pump alarm
DO078 0 = ok, 1 = alarm Run feedback alarm
DO088 0 = ok, 1 = alarm Pump drive fault
DI151 Set pump to hand mode
DI152 Set pump to o
DI153 Set pump to auto mode
AO040 0-1000 (0%-100%) Pump speed
AO053 0-10000 (0-1000.0) amps Pump drive current
AO054 0-10000 (0-1000.0) VAC Pump drive AC voltage
AO055 0-10000 (0-1000.0) kW Pump drive power
AO056 0-1000 (0.0-100.0) % Pump drive speed feedback
AO093 0-32767 (0.0-3276.7) Pump head
AI138 0-1000 (0.0-100.0) % Pump hand speed
AI150 0-9999 (0.0-999.9) Design head
AI151 0-9999 (0.0-999.9) Zero flow head
AO1003 0-32767 Pump flow
AO1014 0-999 hours Pump operating run hours
AO1015 0-32000 hours * 1000 Pump operating run Khours
AO1050 0-32767 (0-327670) Flow design
