FAB

ntelligent

ontrollerr

Note:

1.“L+” line should be connected to “L+” of FAB Power supply, and the load

should be directly connected to the “M-” of the load power.

2.The load voltage should be not more than DC80V.

2.2.4 FAB network connection

FAB 1 FAB 2 FAB 3 FAB n

Fig. 2.13 connecting method

Note

AF-C485/D485

Without any intermediate relay, RS485 bus will only permit 32 FABs

to be linked up.

}

485 Power Bus (5V)

}

485 Message Bus

AF-C485/D485

.......
