Technical Specifications
Synergy
RF
System Service Guide
DFU-0276-4r0_fmt_en-US Page 17 of 50
3.0 Technical Specifications
3.1 Console
Table 9 AR-9800 Console Specifications
Width
40.64 cm (16.00 inches)
Height
13.335 cm (5.250 inches)
Depth
37.338cm (14.7 inches)
Weight
6.8 kg (15 lbs.)
Water protection
IP22
Mains cable
10 A/250 V
Power entry module
IEC 320/C13
Fuse value
8.0 A, 250 V~, 2.0 cm (0.75 inches) Type T
AC input
100-240V~, 50/60Hz, 8.0A, Class I
Applied Part Type
CF
Peak Power Output
575 W (Ablate setting 9 with 218Ω load)
3.2 Ambient Conditions for Operation
Table 10 AR-9800 Ambient Conditions for Operation
Temperature
10° to 40°C (50° to 104°F)
Relative humidity
20% to 75%
Air Pressure
700 hPa to 1060 hPa (21 in. Hg to 31.3 in. Hg)
3.3 Ambient Conditions for Storage (in shipping packaging)
Table 11 AR-9800 Ambient Conditions for Storage
Temperature
-30° to 70°C (-22° to 158°F)
Relative humidity
10% to 90%, non-condensing
Air Pressure
500 hPa to 1060 hPa (15 in. Hg to 31.3 in. Hg)
3.4 Synergy
RF
Footswitch
Table 12 Synergy Footswitch Specifications
Functions
Ablate, Coag, Power setting change
Width
23.6 cm (9.3 inches)
Height
2.5 cm (1.0 inches)
Depth
20.8 cm (8.2 inches)
Weight
2.2 kg (5 lbs.)
Water protection
IP68
