DFU-0276-4r0_fmt_en-US Page 26 of 50
the name and model number. If the tests discover a problem, the problem is
shown on the display. Refer to Table 4 for a listing of AR-9800 Display Messages.
WARNING!
To avoid the RISK of electric shock, this equipment must only be connected to a
SUPPLY MAIN with Protective Earth Terminal.
Do not have device in direct contact with patient if the patient requires
defibrillation.
4.3 Replacing the Fuses
Main fuse is replaced with T8.0AL250v as follows:
Disconnect the device from the Supply Main.
Open the fuse tray in the AC inlet, by pulling out on the tabs.
Replace the fuses with T8.0AL250v Line Fuses as noted on the rear panel.
Push the fuse holder back into the AC inlet.
Ensure that fuse holder is fully seated and that the tabs snap back
Always use fuses with the correct values to avoid allowing
overcurrent to enter the system.
An incorrect fuse may increase the risk of electrical shock or fire
hazard.
NOTE: The AR-9800 console incorporates a universal AC input power supply.
A voltage selection switch is not required.
4.4 Electromagnetic Compatibility
This device has passed testing for EMI / RFI radiation and
susceptibility and EMC compatibility. This device may cause
interference to other devices in the near vicinity if not set up and
used as Arthrex instructs.
AR-9800 has been designed to accept EMC from other devices within the
limitations as described in Section 10.
To determine if the AR-9800 is causing interference to other devices, power OFF
the supply main switch and then ON again.
Try to correct the interference by following one or more of these measures:
