9.1.7. Controller
Controller Values Description
Global MIDI Channel [1(d)-16]
Knob 1.....5
CC [0-127]
Port [USB, MIDI 1, MIDI 2, All(d)]
Channel [1-16, Global(d)]
Mode [Absolute(d), Relative1, Relative2, Relative3]
Min [0(d)-127]
Max [0-127(d)]
These parameters enable you to set up the KeyStep Pro as a controller.
'Global MIDI Channel' sets the default MIDI channel on which the KeyStep Pro will transmit.
The Knob (encoder) settings define the functionality of the five main encoders. Each encoder
can have a different profile. For example, Encoder 1 (Pitch) could transmit CC 9 on MIDI
channel 5 via MIDI Out 2 over the full range of 0-127, while Encoder 2 (Gate) could transmit
CC 19 on MIDI channel 6 via MIDI Out 1 with the range set to a minimum of 50 and a
maximum of 80.
Arturia - User Manual Keystep Pro - KeyStep Pro Configuration 123
