Page 3-3
Interpreting the Hub LEDs
Interpreting the Hub LEDs
When you first turn on your Asanté 10T Hub, all the LEDs switch
ON
while
the hub goes through a series on internal diagnostics ensuring its reliable
operation. After the diagnostics have been completed, each LED indicates a
different condition. Below is a description of each LED.
Table 3-1 Hub LED Description
LED Name Functional Definition
Power/Traffic ON indicates that power is applied to the
hub.
When there is network traffic, this LED
will blink on and off to indicate traffic.
Link Status Each LED indicates the link status of the
corresponding port.
A steady green LED indicates that the
Link Status test has passed and the
connection from the workstation to the
hub is good.
No light indicates that the connection
may be broken. In order to be sure that
the connection from the hub to the
workstation is also good (there are two
pairs of wires in the cables), the link
status light on the adapter card should
also be checked.
10T Hub Ch 3 Page 3 Thursday, August 22, 1996 4:27 PM
