ASD FieldSpec 3 - Power Input and Output; Fieldspec Wavelength Configuration

ASD Document 600540 Rev. J 3 FieldSpec® 3 User Manual
www.asdi.com Chapter 1 Introduction
1.1.2 Power Input and Output
The near infrared (NIR) is also called the short-wave infrared (SWIR).
1.1.3 FieldSpec Wavelength Configuration
AC Power Supply Type Auto ranging, Switching, SELV
AC Input 90-240 VAC, 50/60 Hz
DC Input +12 VDC, 60 W
Accessory Power Port 
(front of instrument)
Output, +12 VDC, 27 Watt (max).
Instrument Configuration Power Rating Maximum
350-1050nm 12 VDC, 45 Watt
350-1800nm 12 VDC, 50 Watt
1000-1800nm 12VDC, 50 Watt
1800-2500nm 12 VDC, 50 Watt
1000-2500nm 12 VDC, 60 Watt
350-2500nm 12 VDC, 60 Watt
Wavelength Name Wavelength Range
VNIR-SWIR1-SWIR2 350 - 2500 nm
VNIR only 350 - 1050 nm
VNIR-SWIR1 350 - 1800 nm
SWIR1 only 1000 - 1800 nm
SWIR1-SWIR2 1000 - 2500 nm
SWIR2 only 1800 - 2500 nm
VNIR & SWIR2 350 - 1050 nm and 1800 - 2500 nm
