DBT12/15/24 Operations Manual....27
BOOST2 or BOOST3).
DBTxxxx SHORE SHIP-L1 SHIP-L2 xx.xHz
VOLTAGE: xxxV xxxV xxxV OK
CURRENT: xxA xxA xxA BOOST1
LOAD: xx.xkVA x.xkVA x.xkVA 1/2
Verify that the shore voltage and frequency displayed are the expected values. Also, ensure that
the load is within the unit ratings. Monitor the shore voltage and current levels with load applied.
Refer to published rating curves for maximum current, kVA and kW levels.
NOTE: It is normal under no load conditions to have up to 2 Amps of input current flowing. This
current does not degrade the unit power rating.
After 5 seconds the display will sequence to the second summary screen indicating the unit model
and the following shore and ship information: frequency, real power, power factor, and load level.
The screen also includes the unit status and voltage gain.
DBTxxxx SHORE SHIP-L1 SHIP-L2 xx.xHz
POWER: xx.xkW x.xkW x.xkW OK
P.F.: x.x x.x x.x BOOST1
LEVEL: xx % xx % xx % 2/2
The display will continue alternating between the two summary screens every 5 seconds.
