DBT12/15/24 Operations Manual....32
7.1. PARALLELING MASTER PHYSICAL SPECIFICATIONS
Parameter DBT12P DBT15P DBT24P
7.1.1. Mechanical
Height
12.06
"
(30.6 cm)
TBD
Width
13.69
"
(34.8 cm)
TBD
Depth
16.88
"
(42.9 cm)
TBD
Weight
39 lbs. (17.7 kg)
48 lbs.
(21.8 kg)
TBD
7.1.2. Environmental
Ambient Temperature Range
0
-
45

C non
-
condensing
Air Exchange Rate
171 CFM
(
4.83 m
3
/min
)
7.2. PARALLELING MASTER MECHANICAL INSTALLATION
The following recommended clearances must be considered during installation:
Table 2: Recommended Installation Clearances
Parameters Proper Operation Proper Service
Front 12" (30 cm)
(User Access)
12" (30 cm)
Left Side 6" (15 cm)
(
Air
Outlet
or
Intake)
12" (30 cm)
(Air Intake
–
Option
628807)
Right Side 6" (15 cm)
(Air Intake or Outlet)
12" (30 cm)
(Air Intake – Default Configuration
or
Side Cable Entry Installation)
Top
None
14
"
(35 cm)
Rear
None
2
"
(5 cm)
The outline and mounting details are shown in Figure 13 and Figure 14.
