After 5 seconds the display will sequence to the second summary screen indicating the following
ship power information: frequency, voltage, current and load level.
SLV1-1 SLV1-2 SLV2-1 SLV2-2 xx.x
xxxV xxxV xxxV xxxV PARALLEL
xxA xxA xxA xxA BOOST1
xx % xx % xx % xx % 2 of 3
After another 5 seconds the display will sequence to the third summary screen indicating the
following ship power information: frequency, apparent and real power, and power factor.
SLV1-1 SLV1-2 SLV2-1 SLV2-2 xx.x
xx.xkVA xx.xkVA xx.xkVA xx.xkVA PARALLEL
xx.xkW xx.xkW xx.xkW xx.xkW BOOST1
x.xPF x.xPF x.x PF x.x PF 3 of 3
Verify that the shore power voltages and frequency displayed are the expected values. Also,
ensure that the load is within the unit ratings. Monitor the shore power voltage and current levels
with load applied. Refer to published rating curves for maximum current, kVA and kW levels.
NOTE: It is normal under no load conditions to have up to 2 Amps of input current flowing. This
current does not degrade the unit power rating.
The display will continue alternating between the three summary screens every 5 seconds.
The Trident System operates in one of the following modes:
Parallel
Two Singles
Slave 1 or Slave 2
Standby
The operating modes will be explained in detail in the following sections.
