Description
Since the appliances for which these instructions were drawn up may have different equipment,
some functions or equipment may be described in the manual that may not be present in your
appliance.
1. Bridge Induction Cooking zone 18 x 22 cm / 2.3 kW / 3.7 kW (boost) to be operated with 'a'
2. Bridge Induction Cooking zone 18 x 22 cm / 2.3 kW / 3.7 kW (boost) to be operated with 'b'
3. Connected Bridge Induction cooking zones (1 and 2) to be operated with 'a'
4. Extraction module
5. Bridge Induction Cooking zone 18 x 22 cm / 2.3 kW / 3.7 kW (boost) to be operated with 'd'
6. Bridge Induction Cooking zone 18 x 22 cm / 2.3 kW / 3.7 kW (boost) to be operated with 'c'
7. Connected Bridge Induction cooking zones (5 and 6) to be operated with 'c'
8. Control panel (visible only when the hob is turned on)
14
Your hob with integrated extractor
