Built-in
This unit can be connected to various discharge systems:
To a plasma filterTo a recirculation filterTo an exhaust duct (outlet)
After filtration through grease
filters and the odour control/fine
After filtration through grease
filters and odour control filters,
After filtration through grease
filters, the extracted air is
particle filter, the extracted air is
discharged back into the room.
the extracted air is discharged
back into the room.
discharged to the outside
through a series of ducts (to be
purchased separately).
Required part:Required parts:
Required parts: •• PlasmaMade filter (HF4004)Recirculation set including
ducts (HR0013)• Connection piece (HD2001)
•• Replace combi-filter
odour/fine dust (HF3010)
Exhaust air duct (HD1001)
• Vertical / horizontal elbow
1. Hook the Y-duct into the lower edge of both motor housings and tilt the Y-duct up.
2. Attach the Y-duct to the motor housings with the two screws.
72
