1. Remove the drawers and the back panel from the kitchen cabinet.
2. Before installing the appliance into a kitchen worktop, attach the foam gasket supplied with
the appliance to the bottom side of the glass ceramic hob.
3. Remove the protective film from the gasket.
4. Attach the gasket to the bottom side of the glass (2–3 mm away from the edge). The gasket
has to be applied along the entire edge of the glass. The gasket may not overlap in the corners.
When fitting the gasket, make sure it is not damaged by or in contact with any sharp objects.
73
Installation
