Connecting to an exhaust duct (outlet)
BA
1. Place the appliance in the cut-out in the worktop.
2. Measure the distance as indicated in the figure and add 35 mm.
3. Saw the flat duct to size.
DC
4. Install the coupling, flat duct, and Naber elbow set.
5. Make the duct airtight with sealing tape.
74
Installation
