Asko HIHD854GF - Page 75

Connecting to a recirculation filter
BA
1. Place the appliance in the cut-out in the worktop.
2. Mark the centre of the cabinet bottom with a strip of masking tape.
DC
550 mm
310 mm
90 mm
550 mm
310 mm
3. Mark the corners of the cut-out using the template provided.
4. Saw the cut-out in the cabinet bottom and finish the cut surfaces moisture resistant.
75
Installation
