C01 CABINET 3610812350 SGCC 0.8T 1 1 PIECE SVC PART
C02 FRAME TOP L 3612206500 SGCC 1.6T 1
C03 FRAME TOP R 3612206600 SGCC 1.6T 1
C04 BASE UNDER 3610392900 SGCD 0.8T 1
C05 LOCK HARNESS M 3613802400 NYLON 12
C06 FRAME UPPER AS 3612207910 SGCC 1.2T + FORM 1
- SCREW TAPPING 7122401411 T2S TRS 4x14 6
For fixing Frame Upper to Cabinet
C07 COVER BACK 3611427900 SGCC 0.6T 1
- SCREW TAPPING 7112401411 T1 TRS 4x14 12 For fixing Cover Back
C08 COVER DUCT 3611428010 ABS, WHITE 2 TL751/G/CA XXLW
3611428060 ABS, PLATINUM 2 TL751/G/CA XXLPP
3611428070 ABS, RED ROSE 2 TL751/G/CA XXLRR
C09 FIXTURE PLATE 3612008000 POM 6
- SCREW TAPPING 7121401211 T2S PAN 4x12 6 For fixing Plate T & Cabinet F
C10 SUPPORTER LEG F 3615304200 SECC 3.0T 2
C11 SUPPORTER LEG R 3615304300 SECC 3.0T 2
C12 FIXTURE LEG 3612006400 ABS 4
C13 FOOT AS 3612100700 HYBRA+NYLON66 4
- SCREW TAPPING 7122401411 T2S TRS 4x14 2 For fixing Supporter Leg F/R
C14 PCB DRYER MAIN AS PRPSSWAD40 UL, Electric main 1 Electric type
PRPSSWAD60 UL, Gas main 1 Gas type
- SCREW TAPPING 7122401411 T2S TRS 4x14 2 For fixing Main PCB to Cabinet
C15 HARNESS AS 3612797000 UL, E-Dryer Main Harness 1 Electric type
3612797300 CSA, G-Dryer Main Harness 1 Gas type
- SCREW TAPPING 7121401411 T2S TRS 4x14 6 For fixing Terminal Block
- SPECIAL SCREW 7S422X4081 TT3 TRS 4x8 SE MFZN 2 For fixing Earth Wire
C16 COVER TERMINAL 3611428100 SGCC 1.0T 1 Electric type
CORD POWER AS 3611340400 UL.SJT 16AWG 3C 125V 13A LP31 1 Gas type
- SCREW TAPPING 7112401411 T1 TRS 4x14 1 For fixing Cover Terminal
C17 PIPE EXHAUST AS 3614413500 SGCC 0.5T + SECC 0.8T 1
- SCREW TAPPING 7112401008 T1 TRS 4x10 SUS 1 For fixing Pipe Exhaust AS
No. Part Name Part Code Description Qtt'y Remark
To Next Page
