NETWORK-SWITCH-LP01 – Configuration Guide
U-0641-3675.docx – Issue: 01 complete, approved
Page 3 of 28
1 Introduction
This Configuration Guide describes how to configure ASL NETWORK-SWITCH-LP01 for use in an ASL
PAVA system. It covers fault reporting, SFP speed, ASL Secure Loop (RSTP), and additional configuration
for systems that include VIPEDIA-12-PRO and/or INTEGRA-PRO units.
The instructions in this document are correct for network switch software V1.0.1.S0. Newer or older software
may provide different features or have different configuration options.
Features not covered in this Configuration Guide are covered in the NETWORK-SWITCH-LP01 User
Manual. For access, go to the ASL website at www.asl-control.co.uk or scan the QR code on page 2.
1.1 Port Capabilities
NETWORK-SWITCH-LP01 has the following port capabilities:
• 8 x RJ45 copper 10/100 Mbps connection speed.
• 2 x SFP 100/1000 Mbps connection speed.
1.2 Required PC Tools and PC Configuration
NETWORK-SWITCH-LP01 configuration requires:
1. A PC (Windows 10) with the network interface configured correctly to communicate with the network
switch.
For instructions, refer to section 4 APPENDIX – PC Requirements on page 23.
2. A web browser.
1.3 Systems Containing VIPEDIA-12-PRO and/or INTEGRA-PRO
The NETWORK-SWITCH-LP01 is compatible with systems containing VIPEDIA-12-PRO and/or INTEGRA-
PRO units where the overall network traffic is no greater than 30 Mbps. This includes all traffic from the ASL
system, non-ASL equipment, and Dante.
Use the following figures to estimate the overall network traffic:
1. Each Dante multicast flow is between 3 Mbps (containing 1 channel, the minimum) to 11 Mbps
(containing 8 channels, the maximum).
2. Each Dante unicast flow is approximately 6 Mbps (containing up to a maximum of 4 channels).
3. Each ASL audio stream (over PMC)
1
is approximately 1 Mbps.
To estimate the overall network traffic, add the expected number of Dante multicast and unicast flows to the
expected number of concurrent ASL audio streams.
Other network traffic has negligible impact on the overall network traffic.
1
ASL audio sources are routed to remote units over IP using ASL's PMC format.
VIPEDIA-12-PRO and/or INTEGRA-PRO audio inputs configured as Dante are automatically
configured as multicast flows when using the “Export Dante Controller File” feature in the PAVA
System Configuration Tool.
If all twelve inputs are configured, the first eight inputs are in one Dante multicast flow (approx.
11 Mbps) and the next four are in a second Dante multicast flow (approx. 5 Mbps), giving 16 Mbps
traffic.
Note that an input routed over Dante to remote units is also routed over PMC.
