2.4 Installing the Memory Modules (DIMM)
is motherboard provides twelve 288-pin DDR5 (Double Data Rate 5) DIMM slots in two
groups, and supports Single Channel Memory Technology.
Recommended Memory Congurations
CPU1
1 DIMM 2 DIMMS 4 DIMMS 8 DIMMS 10 DIMMS 12 DIMMS
A1
V V V V V V
B1
V V V
C1
V V V V
D1
V V
E1
V V V
F1
V
G1
V V V V V
H1
V V V
I1
V V V V
J1
V V
K1
V V V
L1
V
e symbol V indicates the slot is populated.
1. installing a memory module, make sure to turn o the computer and unplug the power-
cord from the power outlet to prevent damage to the memory module.
2. It is not allowed to install a DDR, DDR2, DDR3 or DDR4 memory module into a DDR5
slot; otherwise, this motherboard and DIMM may be damaged.
3. For Twelve channel conguration, it always needs to install identical (the same brand,
speed, size and chip-type) DDR5 DIMMs.
