ASROCK GENOAD12M3-2Q - Page 40

34 35
English
Pin Defeinition Pin Defeinition
A1 GND B1 GND
A2 G1_RXP0 B2 G1_TXP0
A3 G1_RXN0 B3 G1_TXN0
A4 GND B4 GND
A5 G1_RXP1 B5 G1_TXP1
A6 G1_RXN1 B6 G1_TXN1
A7 GND B7 GND
A8 BP_TYPE B8 SCL
A9 PCIE _WAKE# B9 SDA
A10 GND B10 GND
A11 DP B11 BUF_RST0_L
A12 DN B12 R_PRSNT_N
A13 GND B13 GND
A14 G1_RXP2 B14 G1_TXP2
A15 G1_RXN2 B15 G1_TXN2
A16 GND B16 GND
A17 G1_RXP3 B17 G1_TXP3
A18 G1_RXN3 B18 G1_TXN3
A19 GND B19 GND
A20 G1_RXP4 B20 G1_TXP4
A21 G1_RXN4 B21 G1_TXN4
A22 GND B22 GND
A23 G1_RXP5 B23 G1_TXP5
A24 G1_RXN5 B24 G1_TXN5
A25 GND B25 GND
A26 BP_TYPE B26 SCL
A27 PCIE _WAKE# B27 SDA
A28 GND B28 GND
A29 DP B29 BUF_RST0_L
A30 DN B30 R_PRSNT_N
A31 GND B31 GND
A32 G1_RXP6 B32 G1_TXP6
A33 G1_RXN6 B33 G1_TXN6
A34 GND B34 GND
A35 G1_RXP7 B35 G1_TXP7
A36 G1_RXN7 B36 G1_TXN7
A37 GND B37 GND
75 NP_NC_1 76 NP_NC_2
77 PGND_1 78 PGND_3
79 PGND_2 80 PGND_4
MCIO5 Pin Denition
