Pin Defeinition Pin Defeinition
A1 GND B1 GND
A2 G0_RXP8 B2 G0_TXP8
A3 G0_RXN8 B3 G0_TXN8
A4 GND B4 GND
A5 G0_RXP9 B5 G0_TXP9
A6 G0_RXN9 B6 G0_TXN9
A7 GND B7 GND
A8 BP_TYPE B8 SCL
A9 PCIE _WAKE# B9 SDA
A10 GND B10 GND
A11 DP B11 BUF_RST0_L
A12 DN B12 R_PRSNT_N
A13 GND B13 GND
A14 G0_RXP10 B14 G0_TXP10
A15 G0_RXN10 B15 G0_TXN10
A16 GND B16 GND
A17 G0_RXP11 B17 G0_TXP11
A18 G0_RXN11 B18 G0_TXN11
A19 GND B19 GND
A20 G0_RXP12 B20 G0_TXP12
A21 G0_RXN12 B21 G0_TXN12
A22 GND B22 GND
A23 G0_RXP13 B23 G0_TXP13
A24 G0_RXN13 B24 G0_TXN13
A25 GND B25 GND
A26 BP_TYPE B26 SCL
A27 PCIE _WAKE# B27 SDA
A28 GND B28 GND
A29 DP B29 BUF_RST0_L
A30 DN B30 R_PRSNT_N
A31 GND B31 GND
A32 G0_RXP14 B32 G0_TXP14
A33 G0_RXN14 B33 G0_TXN14
A34 GND B34 GND
A35 G0_RXP15 B35 G0_TXP15
A36 G0_RXN15 B36 G0_TXN15
A37 GND B37 GND
75 NP_NC_1 76 NP_NC_2
77 PGND_1 78 PGND_3
79 PGND_2 80 PGND_4
MCIO8 Pin Denition
