Step 3
Move the stando based on the
module type and length.
Skip Step 3 and 4 and go straight to
Step 5 when using the default nut.
Otherwise, release the stando by
hand.
BC
A
Step 4
Peel o the yellow protective lm on
the nut to be used. Hand tighten the
stando into the desired nut location
on the motherboard.
20
o
BC
A
BC
A
Step 5
Align and gently insert the M.2 SSD
module into the M.2 slot. Please be
aware that the M.2 SSD module only
ts in one orientation.
NUT1NUT2
C
Step 6
Tighten the screw with a screwdriver
to secure the module into place.
Please do not overtighten the screw
as this might damage the module.
