Programming Instructions:
The eForce
®
150 can support 152 individual codes. Each code is assigned a
code location (1-152) in addition to a user name and the code’s programmed
digits. Program Command Code 51 is used for programming Master, Emer-
gency, Supervisor, Lockout, Passage, Normal, and One Time User codes.
The Master code is always code location number 1 and can be used to oper-
ate and program the eForce
®
150. Use the included record log to assign and
log all codes before proceeding on to programming. Store the log in a secure
location.
eFORCE
®
150 PROGRAMMING GUIDE:
FOLLOW STEPS 1 THROUGH 7
STEP 1: MASTER CODE (Quick Step Programming)
(Location 1)
Depress and hold # key (approximately 5 seconds).
Release when yellow LED blinks. (Yellow LED will blink continuously
during programming)
Enter 1234 # (Green flash with 2 short
tones)
Enter 51 # (Green flash with 2 short tones)
Enter 1 # (Green flash with 2 short tones)
Enter new Master Code # (4-7 digits) (Green flash with 2 short tones)
Re-Enter new Master Code # (Green flash with 2 short tones)
Green flash with 2 short tones will repeat to indicate successful code
programming
Press # within 2 seconds to stay in programming mode, and then
enter 51# to continue steps 2 through 7.
(Note* if Master Code is lost, the controller’s Master and Emergency
Codes may be reset to factory defaults (1234 and 4321 respectively). To
accomplish this task:
80-0180-262 Rev. D 21 February 2012
TROUBLE SHOOTING:
Green light comes on, but lever will not retract latch-bolt.
Check the eForce
®
150 body connection with lock/latch mechanism.
Check the cylinder tailpiece length (see installation instructions).
Check for proper door preparation (refer to door templates).
No lights come on when pushbuttons are depressed.
Ensure Visual Keypad Feedback is set to Enable (PCC32).
Check battery installation.
Check 6 Volt battery
Check keypad terminal connection.
No tones sound when pushbuttons are depressed.
Ensure Audible Keypad Feedback is set to Enable (PCC 31).
Check battery installation.
Check 6 Volt battery
Check keypad terminal connection.
Factory default codes not working.
Delete all users and reprogram default codes.
User codes not working.
Ensure Lockout code has not been entered.
Check battery power (operator may be in blackout mode). See above for
battery replacement.
Check eForce
®
150 body connection.
Operator stays unlocked.
Ensure Passage code has not been entered.
Check cylinder tailpiece length (see installation instructions).
Check eForce
®
150 body connection.
To Next Page
