12. APPENDIX A
These are additional specifications for the OMNIA II for the AC and DC filtering.
LEAKAGE LIMIT SETTING
Touch Current High Limit (AC+DC)
Range:
0.0uA ~ 999.9uA
1000uA ~ 10.00mA
Resolution:
0.1uA / 1uA / 0.01mA
Touch Current Low Limit (AC+DC)
Range:
0.0uA ~ 999.9uA
1000uA ~ 10.00mA
Resolution:
0.1uA/1uA/0.01mA
Touch Current High Limit (AC Only)
Range:
0.0uA ~ 999.9uA
1000uA ~ 10.00mA
Resolution:
0.1uA / 1uA / 0.01mA
Touch Current Low Limit (AC Only)
Range:
0.0uA ~ 999.9uA
1000uA ~ 10.00mA
Resolution:
0.1uA/1uA/0.01mA
Touch Current High Limit (DC Only)
Range:
0.0uA ~ 999.9uA
1000uA ~ 10.00mA
Resolution:
0.1uA / 1uA / 0.01mA
Touch Current Low Limit (DC Only)
Range:
0.0uA ~ 999.9uA
1000uA ~ 10.00mA
Resolution:
0.1uA/1uA/0.01mA
Touch Current High Limit (Peak)
Range:
0.0uA - 999.9uA
1000uA ~ 10.00mA
Resolution:
0.1uA/1uA/0.01mA
Touch Current Low Limit (Peak)
Range:
0.0uA - 999.9uA
1000uA ~ 10.00mA
Resolution:
0.1uA/1uA/0.01mA
