25
DISPLAY (CONT.)
Range 4
400uA ~ 2100uA, frequency DC
- 1MHz
Resolution
1uA
Accuracy
DC : ±(2% of reading + 2uA)
15Hz < f < 1MHZ : ±10% of
reading + 2uA
Range 5
1800A ~ 8500uA, frequency DC
- 1MHz
Resolution
1uA
Accuracy
DC : ±(2% of reading + 2uA)
15Hz < f < 1MHZ : ±10% of
reading + 2uA
Range 6
8.0mA ~10.00mA, frequency
DC – 100KHz
Resolution
0.01mA
Accuracy
DC : ±(2% of reading + 3counts)
15Hz < f < 100KHz : ±10% of
reading + 2counts
MD CIRCUIT MODULE
MD1
UL544NP, UL484 , UL923, UL471, UL867, UL697
MD2
UL544P
MD3
IEC 60601-1
MD4
UL1563
MD5
IEC60990 Fig4 U2, IEC 60950-1, IEC60335-1,
IEC60598-1, IEC60065, IEC61010
MD6
IEC60990 Fig5 U3, IEC60598-1
MD7
IEC60950, IEC61010-1 FigA.2 (2K ohm) for Run
function.
External MD
Basic measuring element 1k ohm
Scope Output Interface
BNC type connector on rear panel for
Oscilloscope connection
MD voltage limit
Maximum 70VDC
MD Component Accuracy
Capacitors = 5%
Resistors = 1%
