Astraada DRV-24 frequency inverters Communication protocol
106
Function
instruction
Address
definition
Data meaning instruction
R/W
characteristics
0006H: pre-exciting state
SW 1 of the
inverter
2101H
Bit0: =0:bus voltage is not established
=1:bus voltage is established
Bi1~2:=00:motor 1 =01:motor 2
=10:motor 3 =11:motor 4
Bit3: =0:asynchronous motor
=1:synchronous motor
Bit4:=0:pre-alarm without overload
=1:overload pre-alarm
Bit5~ Bit6:=00: keypad control
=01:terminal control
=10:communication control
R
Fault code of
the inverter
2102H
See the fault type instruction
R
Identifying code
of the inverter
2103H
DRV-24-----0x0106
R
Operation
frequency
3000H
Range: 0.00Hz~P00.03
R
Setting
frequency
3001H
Range: 0.00Hz~P00.03
R
Bus voltage
3002H
Range: 0~2000V
R
Output voltage
3003H
Range: 0~1200V
R
Output current
3004H
Range: 0.0~3000.0A
R
Operation
speed
3005H
Range: 0~65535RPM
R
Output power
3006H
Range: -300.0~300.0%
R
Output torque
3007H
Range: -250.0~250.0%
R
Close loop
setting
3008H
Range: -100.0%~100.0%
R
Close loop
feedback
3009H
Range: -100.0%~100.0%
R
PID setting
3008H
-100.0~100.0% (unit: 0.1%)
R
PID feedback
3009H
-100.0~100.0% (unit: 0.1%)
R
Input IO
300AH
000~1FF
Input IO
300BH
000~1FF
AI 1
300CH
Range: 0.00~10.00V
R
AI 2
300DH
Range: 0.00~10.00V
R
AI 3
300EH
Range: 0.00~10.00V
R
AI 4
300FH
Range: -10.00~10.00V
R
Read high
speed pulse 1
input
3010H
Range: 0.00~50.00kHz
R
Read high
3011H
Reserved
R
