Astraada DRV-24 frequency inverters Function Parameters
61
Functio
n code
Name
Detailed instruction of parameters
Defaul
t value
Modify
P07.49
Reference
frequency
at previous
2 faults
0.00Hz
P07.50
Ramp
reference
frequency
at previous
2 faults
0.00Hz
P07.51
Output
voltage at
previous 2
faults
0V
P07.52
Output
current at
previous 2
faults
0.0A
P07.53
Bus voltage
at previous
2 faults
0.0V
P07.54
The Max.
temperatur
e at
previous 2
faults
0.0°C
P07.55
Input
terminals
state at
previous 2
faults
0
P07.56
Output
terminals
state at
previous 2
faults
0
P08 Group Enhanced functions
P08.00
ACC time 2
Refer to P00.11 and P00.12 for detailed
definition.
Astraada DRV-24 series define four groups of
ACC/DEC time which can be selected by P5
group. The first group of ACC/DEC time is the
factory default one.
Setting range:0.0~3600.0s
Depen
d on
model
P08.01
DEC time 2
Depen
d on
model
P08.02
ACC time 3
Depen
d on
model
P08.03
DEC time 3
Depen
d on
