Astraada DRV-24 frequency inverters Function Parameters
62
Functio
n code
Name
Detailed instruction of parameters
Defaul
t value
Modify
model
P08.04
ACC time 4
Depen
d on
model
○
P08.05
DEC time 4
Depen
d on
model
○
P08.06
Jogging
running
frequency
This parameter is used to define the reference
frequency during jogging.
Setting range: 0.00Hz ~P00.03(the Max.
frequency)
5.00Hz
○
P08.07
Jogging
running ACC
time
The jogging ACC time means the time needed if
the inverter runs from 0Hz to the Max.
Frequency.
The jogging DEC time means the time needed if
the inverter goes from the Max. Frequency
(P00.03) to 0Hz.
Setting range:0.0~3600.0s
Depen
d on
model
○
P08.08
Jogging
running DEC
time
Depen
d on
model
○
P08.09
Jumping
frequency 1
When the set frequency is in the range of
jumping frequency, the inverter will run at the
edge of the jumping frequency.
The inverter can avoid the mechanical
resonance point by setting the jumping
frequency. The inverter can set three jumping
frequency. But this function will be invalid if all
jumping points are 0.
Set frequency f
Time t
Jump
frequency 2
1/2*Jump
frequency range 2
1/2*Jump
frequency range 2
Jump
frequency 1
1/2*Jump
frequency range 1
1/2*Jump
frequency range 1
Jump
frequency 3
1/2*Jump
frequency range 3
1/2*Jump
frequency range 3
Setting range: 0.00~P00.03(the Max.
frequency)
0.00Hz
○
P08.10
jumping
frequency
range 1
0.00Hz
○
P08.11
Jumping
frequency 2
0.00Hz
○
P08.12
Jumping
frequency
range 2
0.00Hz
○
P08.13
Jumping
frequency 3
0.00Hz
○
P08.14
Jumping
frequency
range 3
0.00Hz
○
P08.15
Traverse
range
This function applies to the industries where
traverse and convolution function are required
such as textile and chemical fiber.
The traverse function means that the output
frequency of the inverter is fluctuated with the
set frequency as its center. The route of the
running frequency is illustrated as below, of
which the traverse is set by P08.15 and when
0.0%
○
P08.16
Sudden
jumping
frequency
range
0.0%
○
P08.17
Traverse
boost time
5.0s
○
