Astraada DRV-24 User Manual

Astraada DRV-24 frequency inverters Function Parameters
80
Functio
n code
Name
Detailed instruction of parameters
Defaul
t value
Modify
n fault
processing
1:No alarm and continue to run
2:No alarm and stop according to the stop
means(only under the communication control)
3:No alarm and stop according to the stop
means(under all control modes)
P14.06
Communica
tion
processing
0x00~0x11
LED ones:
0: Write with response: the inverter will
respond to all reading and writing commands
of the upper monitor.
1: Write without response: the inverter only
responds to the reading command other than
the writing command of the drive. The
communication efficiency can be increased by
this method.
LED tens:(reserved)
0: Communication encrypting valid
1: Communication encrypting invalid
0x00
○
P14.07
Reserved
●
P14.08
Reserved
●
P17 Group Monitoring function
P17.00
Setting
frequency
Display current set frequency of the inverter
Range: 0.00Hz~P00.03
●
P17.01
Output
frequency
Display current output frequency of the
inverter
Range: 0.00Hz~P00.03
●
P17.02
Ramp
reference
frequency
Display current ramp reference frequency of
the inverter
Range: 0.00Hz~P00.03
●
P17.03
Output
voltage
Display current output voltage of the inverter
Range: 0~1200V
●
P17.04
Output
current
Display current output current of the inverter
Range: 0.0~5000.0A
●
P17.05
Motor
speed
Display the rotation speed of the motor.
Range: 0~65535RPM
●
P17.06
Torque
current
Display current torque current of the inverter
Range: 0.0~5000.0A
●
P17.07
Magnetized
current
Display current magnetized current of the
inverter
Range: 0.0~5000.0A
●
