Astraada DRV-24 frequency inverters Function Parameters
82
Functio
n code
Name
Detailed instruction of parameters
Defaul
t value
Modify
P17.22
HDI input
frequency
Display HDI input frequency
Range: 0.00~50.00kHz
P17.23
PID
reference
value
Display PID reference value
Range: -100.0~100.0%
P17.24
PID
feedback
value
Display PID feedback value
Range: -100.0~100.0%
P17.25
Power
factor of the
motor
Display the current power factor of the motor.
Range: -1.00~1.00
P17.26
Current
running
time
Display the current running time of the
inverter.
Range:0~65535min
P17.27
Simple PLC
and the
current
stage of the
multi-step
speed
Display simple PLC and the current stage of the
multi-step speed
Range: 0~15
P17.28
ASR
controller
output
The percentage of the rated torque of the
relative motor, display ASR controller output
Range: -300.0%~300.0% (the rated motor
current )
P17.29
Reserved
P17.30
Reserved
P17.31
Reserved
P17.32
Magnetic
flux linkage
Display the magnetic flux linkage of the motor.
Range: 0.0%~200.0%
P17.33
Exciting
current
reference
Display the exciting current reference in the
vector control mode.
Range: -3000.0~3000.0A
P17.34
Torque
current
reference
Display the torque current reference in the
vector control mode.
Range: -3000.0~3000.0A
P17.35
AC input
current
Display the input current in AC side.
Range: 0.0~5000.0A
P17.36
Output
torque
Display the output torque. Positive value is in
the electromotion state, and negative value is
in the power generating state.
