ASUS DAV Center 11
No. Name Description
6.* Composite Video In jack
Plug a yellow RCA cable from a video source into this jack on the
tuner card.
7.* S-Video in jack
Plug an S-Video cable from a video source into this jack on the tuner
card.
8.* TV In jack Plug a TV signal cable into this jack on the tuner card.
9. WiFi Antenna connector Plug a wireless LAN antenna into this connector.
10. ESATA port Connect to an external drive.
11. S/PDIF Out port (optical)
Plug an optical (Toslink) digital audio cable into this port for digital
audio transfer.
12. S/PDIF In port Plug an RCA cable into this jack for digital audio transfer.
13. S/PDIF In port (optical)
Plug an optical (Toslink) digital audio cable into this port for digital
audio transfer.
14. IR1/IR2 ports
Plug the IR control cables into these ports to send input from the
remote control to a set-top box to change channels.
15. Stereo Audio Out jacks
Plug a white (left speaker) and a red (right speaker) RCA cables from
a stereo into these jacks.
16. Stereo Audio In jacks
Connect to a stereo audio source using a white (left) and a red (right)
RCA cables.
17. USB ports x 2
Plug USB devices, a printer, camera, scanner, or keyboard for example,
into these ports.
18. IEEE 1394 port
Plug an IEEE 1394 device, a digital camrecorder for example, into this
6-pin IEEE 1394 port.
19. HDMI
Plug an HDMI (High Definition Multimedia Interface) device into this
port.
20. S-Video Out jack
Plug an S-video cable into this jack to connect to a display, a TV for
example.
21. Video Out port Plug an RCA cable into this jack to connect to a TV.
22. Component video ports
Plug a component video cable into this jack to connect to a VCR,
set-top box, or DVD player.
*For models with one TV tuner card, there is only one set of these four jacks
