Asus P5M2 - Creating a RAID 1 Set (Mirror)

ASUS P5M2 Series
5-27
5.3.2 Creating a RAID 1 set (Mirror)
To create a RAID 1 set:
1. From the utility main menu, select
1. Create RAID Volume
, then press
<Enter>. This screen appears.
Intel(R)MatrixStorageManagerOptionROMv5.0.0.1032ICH7RwRAID5
Copyright(C)2003-05IntelCorporation.AllRightsReserved.
[ CREATE ARRAY MENU ]
[ DISK/VOLUME INFORMATION ]
Enter a string between 1 and 16 characters in length that can be used
to uniquely identify the RAID volume. This name is case sensitive and
cannot contain special characters.
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Volume1
RAID1(Mirror)
SelectDisks
N/A
0.0 GB
Create Volume
[
↑↓
]-Select [ESC]-Exit[ENTER]-SelectMenu
2. Enter a name for the RAID 1 set, then press <Enter>.
3. Highlight
RAID Level, press the up/down arrow key to select
RAID 1 (Mirror)
,
then press <Enter>.
4. Follow steps 4 to 5 and 7 to 9 of the previous section to create the RAID 1
set.
