2. The Select New Array Type screen apprears.
Use the arrow keys to select Create New IME Volume, then press <Enter>.
5.5.2 Integrated Mirroring Enhanced
To create an IME volume:
1. The
Adapter Properties screen appears.
Use the arrow keys to select RAID Properties, then press <Enter>.
Esc=ExitMenuF1/Shift+1=Help
Enter = Select Item -/+ = Change Item
LS I  Lo gi c  Co nf i g U ti l it y             v 6 . 0 8 . 0 5 . 0 0  (2 0 0 6 . 0 8 . 0 2 )
Adapter Properties -- SAS1068
Adapter SAS1068
PCI Slot 00
 PCIAddress(Bus/Dev/Func)05.03.00
 MPTFirmwareRevision1.15.00.00-IR
 SASAddress500E0180:60831008
 NVIDIAVersion25.02
Status Disabled
Boot Order 0
Boot Support (Enabled OS only)
RAID Properties
SAS Topology
Advanced Adapter Properties
Esc=ExitMenuF1/Shift+1=Help
Enter = Choose array type to create
LSILogicCongUtilityv6.08.05.00(2006.08.02)
Select New Array Type -- SAS1068
Create IM Volume Create Integrated Mirror Array of 2
 disksplusanoptionalhotspare.Data
ontheprimarydiskmaybemigrated.
Create IME Volume Create Integrated Mirrored Enhanced
 Arrayof3to8disksincludingan
optional hot spare.
ALL Data onarraydiskswillbedeleted!
Create IS Volume Create Integrated Striping array of
 2to8disks.
ALL Data onarraydiskswillbedeleted!
