ASUS P5M2 Series
4-27
4.4.6 Peripheral Device Configuration
On boa rd Flo ppy Co ntr oll er [En abl ed]
Enables or disables the onboard oppy controller.
Conguration options: [Disabled] [Enabled]
Se ria l P ort 1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Conguration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4] [2E8/IRQ3]
Se ria l P ort 2 Address [2F8/IRQ3]
Allows you to select the Serial Port2 base address.
Conguration options: [Disabled] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Serial Port2 Mode [Normal]
Allows you to select the Serial Port2 mode. This item appears only when the
Serial Port1 item is not Disabled.
Conguration options: [Normal] [IrDA] [ASK IR]
Pa ral lel Po rt Ad dre ss[ 378 ]
Allows you to disable or select parallel port base addresses.
Conguration options: [Disabled] [378] [278] [3BC]
Pa ral lel Po rt Mod e [ Nor mal ]
Allows you to set the parallel port mode.
Conguration options: [Normal] [BI-Directional] [ECP] [EPP] [ECP&EPP]
Pa ral lel Po rt IRQ [I RQ7 l]
Allows you to set the parallel port IRQ.
Conguration options: [IRQ5] [IRQ7]
Select Screen
Select Item
+- Change Option
F1 General Help
F10SaveandExit
ESCExit
CongureW83627EHG-ASuperI0Chipset
OnboardFloppyController [Enabled]
SerialPort1Address  [3F8/IRQ4]
SerialPort2Address  [2F8/IRQ3]
 SerialPort2Mode  [Normal]
ParallelPortAddress  [378]
ParallelPortMode  [Normal]
ParallelPortIRQ  [IRQ7]
