5.3.4 Creating a RAID 5 set (Parity)
To create a RAID 5 set:
1. From the utility main menu, select
1. Create RAID Volume, then press
<Enter>. This screen appears.
Intel(R)MatrixStorageManagerOptionROMv5.0.0.1032ICH7RwRAID5
Copyright(C)2003-05IntelCorporation.AllRightsReserved.
[ CREATE ARRAY MENU ]
[ DISK/VOLUME INFORMATION ]
Enter a string between 1 and 16 characters in length that can be used
to uniquely identify the RAID volume. This name is case sensitive and
cannot contain special characters.
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Volume1
RAID5(Parity)
SelectDisks
128KB
0.0 GB
Create Volume
[↑↓]-Select [ESC]-Exit[ENTER]-SelectMenu
2. Enter a name for the RAID 10 set, then press <Enter>.
3. Highlight RAID Level, press the up/down arrow key to select
|RAID 10
(RAID0+1), then press <Enter>.
4. Follow steps 4 to 9 of section “5.3.1 Creating a RAID 0 set (striped)” to create
the RAID 5 set.
