Chapter 2: Hardware setup2-2
2.1 Chassis cover
2. Firmly hold the cover and slide it
toward the rear panel for about half
an inch until it is disengaged from
the chassis.
3. Lift the cover from the chassis.
1. Loosen the two thumbscrews on the rear panel to release the rear cover from
the chassis.
Removing the rear cover
Thumbscrews
1/2 inch distance
